CombiFlex Pumps

Close-coupled horizontal centrifugal pump to EN 733 (DIN 24255):

• Standardized and modular design
• Compact design
• Flanges according to ISO 7005 PN 16
• Many mounting options (floor, bulkhead, wall mounting)
• Eight positions possible between suction and delivery connections
• Outstanding hydraulic performance
• High efficiency impeller
• Closed impeller with back vanes providing axial balancing of impeller loads
• Spacer-coupling option for easy maintenance
• Easy maintenance through the Top-Pull-Out principle
• Mechanical seal to EN 12756 (DIN 24960)
• Dry-shaft design, pumped liquid not in contact with the shaft
• Robust shaft design
• Extended life time
• 2-Angular contact bearing
• Bearing bracket option allows a wide range of shaft seals
• ATEX Certified

Technical Data

Suitable for:

• Clean, slightly contaminated thin liquids

Unparalleled Support and Customisation:

• Extensive Inventory: Superior Pump Technologies maintains a substantial local stock. Contact us to confirm availability.
• Expert Service: Our skilled technicians can perform pump overhauls and repairs in our fully equipped and SPXFlow approved as certified repair centre workshop.
• Custom Solutions: We possess the expertise to design and build pump units tailored to your specific requirements. This includes compatibility with various drives such as electric, hydraulic, diesel, and more.

Streamlined Selection Process: Contact our knowledgeable team using our enquiry form below. We are happy to provide technical support and assist you in selecting the optimal CombiFlex Pump to suit your application.
